Compressors for High Pressure Fastening Tools

Aerosmith AKHL 1260E & AKHL 1260EX Compressors

Powerful, lightweight at 35.4 lbs, and quiet are just a few descriptions used for the AKHL 1260 compressors. With two sets of air fittings these compressors can serve two standard air tools like the ST4200 and/or two high-pressure tools like the HN25C High-Pressure Pin Nailer and HN120 Pneumatic Fastening Tool. Powered by a 115v, 12A, oil-less, and DC brushless motor the units are not only quiet but also perform anywhere on the job.

Why Aerosmith® Fastening?

Best In Class Performance

Durability & Performance Tested
Building Code Evaluations (ICC & PER Reports) for multiple applications
Get the right tool to match worker & application needs – cut costs!
Reduce/Eliminate call backs

Applications & Industry Uses for the VersaPin Fastening Line:

Fastening in Construction

Industrial Applications

Specialty Applications

Specifications Click to Expand

Model	AKHL 1260E	AKHL 1260EX
Dimensions	Height 13-1/4" Width 12-1/8" Length 23"	Height 18-7/8" Width 15" Length 23"
Weight	35.4lbs.	51lbs.
Maximum Working Pressure	500psi
Motor	2HP
Power Supply	115V (+/-) 10%; 12 amp; 60Hz (+/-) 1%
Tanks	2 stages
Speeds	High Power=2900rpm; Quiet Mode=1600rpm
Tank Volume	2.3 gal.	5.7 gal.
Off/On Pressure Switch Range	Off= 500psi; On= 435psi/DIV

High Pressure Accessories Click to Expand

High Pressure (500psi) Hoses: 50 or 100 foot

High Pressure Air Fittings

HN120 Tool (only), Handle Extender
